TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System

    Buy cheap TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System from wholesalers

    Buy cheap TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System from wholesalers
    • Buy cheap TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System from wholesalers
    • Buy cheap TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System from wholesalers
    • Buy cheap TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System from wholesalers
    • Buy cheap TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System from wholesalers

    TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System

    Ask Lasest Price
    Brand Name : LTMG
    Model Number : FD35
    Certification : CE/ISO
    Price : negotiable
    Supply Ability : 300 Set/Sets per Month
    Delivery Time : 30days
    Payment Terms : Western Union, MoneyGram, L/C, T/T
    • Product Details
    • Company Profile

    TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System

    TCM technology 3 ton and 3.5 ton new forklift prices with 1220mm fork length


    Features of new forklift prices

    1. Physical appearance: Fork lift truck has brilliantly repeated streamline surface modeling and sharpening of shapes to required specification. It has a luxurious appearance, flowing and richly dynamic lines of finishes.
    2. Engine hood: A high quality and high stiffness integral GRP hood. Has greater performance in sound proofing and effective heat insulation effects.
    3. Hydraulic system: Selected from the best qualified and reliable hydraulic component manufacturer that vastly implements advanced technology. It has good performance by sealing fuel tank structure and multi-function valve with forward self-locking
    4. Introduces new technology by using good reliability hand brakes with brake master cylinder and brake light.
    5.. Wide base tires at the front: improves the bearing capacity, prolong tire life-span and improve machines stability.


    Specifications of new forklift prices

    FeaturesManufacturerLTMG
    ModelPower shift T/MFD35T
    Manual shift T/MFD35C
    Operator typeDriver/seat
    Tire typeFront/rearPneumatic
    WheelFront/rear2/2
    DimensionMax. lifting heightmm3000
    Free liftmm150
    Fork sizeL*W*Tmm1070*125*50
    Tilt rangeMast forward/backwarddeg6/12
    Overall length(without fork)mm2760
    Total widthmm1285
    Mast height (fork lowering)mm2075
    Overall height fork raisedWith backrestmm4250
    Height to head guardmm2140
    Turning raduis(outside)mm2495
    Front face of fork to front axlemm485
    Min. right angle stacking aislemm2975
    without load length&clearence
    PerformanceSpeedMax Travellingkm/h18/19.5
    full/no load
    Liftingmm/s450/500
    full/no load
    Loweringmm/s450/420
    full/no load
    Max.drawbar pullPower shift T/Mkg2100/1000
    full/no load
    Manual shift T/Mkg2100/1000
    full/no load
    Gradeability at 1.6km/hPower shift T/M%18/20
    full/no load
    Manual shift T/M%18/20
    full/no load
    Weight distributionFull load front/rearkg7380/900
    No load front/rearkg1820/2960
    FrameTiresNumberfront/rear2/2
    Modelfront axle28x9-15-12PR
    rear axle6.50-10-10PR
    TreadFront/rearmm1060/970
    Ground clearenceAt lowest point(mast)mm120
    Framemm135
    BrakeService brakeHydraulic-foot pedal
    Parking brakeMechanical-hand lever
    EngineBatteryVoltage/capacityV/AH12/80
    EngineModelISUZU 4JG2
    Rated powerkw/rpm44.8/2450
    Rated torqueN.m/rpm186/1800
    Number of cylinders4
    PlacementL3.059
    Fuel tank capacityL70
    TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M1-1 power shift T/M
    2-2 manual shift T/M
    Operating pressureHydraulic system pressurekg/cm²180

    new forklift prices

    TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic SystemTCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System


    After-sale service
    Nowadays we have been sell more than 100 countries. All the products of LTMG supplied withone year or 2000 working hours (which occurs first) period quality warranty.
    If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.
    Detail clauses and policies please see to our website and product's quality certificate.


    Our company

    TCM Technology Diesel Forklift Truck 1220mm Fork Length With Hydraulic System


    FAQ:

    1.What Certificate do you have?
    LTMG workshop meet with the ISO9001:2008 Quality System.
    All of our products with CE certificate. Some of our products meets the EPA requirements.

    2. Can you customize and design as the clients' requirement?
    LTMG will try its best to meet all kinds of clients' special requirements.
    However, All the customizing and refit should be implemented safely and scientifically.
    The colors can be painted as client's need.

    3.How long is the warranty of your products?
    Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

    4. Can you produce the products labeled with the client's brand?
    With the authorization of the brand, we can OEM for our clients.

    5. What payment terms do you accept?
    Normally 30% T/T in advance as deposit, blance paid before shipment.
    100% L/C at sight issued by world famous bank with good faith is also available.

    6.Delivery time:
    Standard configuration products are always in stock.
    The production period of Customizing products is 30 days.
