    3000kg Electric Counterbalance Truck , Battery Power Lift Truck For Factory

    Ask Lasest Price
    Brand Name : LTMG
    Model Number : FB30
    Certification : CE, ISO
    Price : usd 20318 per set
    Payment Terms : T/T, L/C
    Supply Ability : 300 units per month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    3000kg Electric Counterbalance Truck , Battery Power Lift Truck For Factory

    3 ton battery forklift truck electric fork lift with 4500mm triplex mast


    The 3 ton electric forklift feature


    1. Equipped with original imported American Curtis electric control system; High voltage and large capacity battery can supply the forklift with strong power.

    2. This electric forklift truck not only has excellent operability, comfortable and safe, and reliable performance with waterproof.

    3. It won't be emissions, and does not produce noise.

    4. All the parts of reasonable design, combined with a series of designed to increase productivity power regeneration function, to achieve the goal of control power consumption.

    5. Redesigned hydraulic control levers positioned next to seat to make operators feel comfortable.


    The 3 ton electric forklift specification


    Features1ManufacturerLTMG
    2ModelFB30
    3Load capacitykg3000
    4Load centermm500
    5Power unitBattery ,diesel ,gasolineBattery
    6Operator typeDriver/seat
    7Tire typeFront/rearAir tires
    8WheelNumber Front/rear2X/2
    Dimension9Max. lifting heightmm3000
    10Free liftmm165
    11Fork sizeL*W*Tmm1070*125*45
    12Tilt rangeMast forward/backwarddeg6-12
    13Overall length(without fork)mm2510
    14Total widthmm1225
    15Mast height (fork lowering)mm2075
    16Overall height fork raisedWith backrestmm4260
    17Height to head guardmm2190
    18Turning raduis(outside)mm2140
    19Front face of fork to front axlemm485
    20Min. right angle stacking aislenot add load length&clearencemm2080
    Performance21SpeedMax Travelling full/no loadkm/h13.5/15
    22Lifting full loadmm/s290
    23Lifting no loadmm/s490
    25Gradeabilityfull load%12.5
    Weight26Truck weightkg4660
    27Weight distributionFull load front/rearkg3635/555
    28No load front/rearkg1885/2775
    Frame29TiresNumberfront/rear2/2
    30Modelfront axle28x9-15-12PR
    31rear axle18x7-8-14PR
    32Wheelbasemm1600
    33TreadFront/rearmm1000/950
    34Ground clearenceAt lowest point(mast)mm140
    Framemm120
    35BrakeService brakeHydraulic-foot peda
    Parking brakeMechanical lever
    Electric motor and controller36BatteryVoltage/capacityV/AH/5hr72V-480
    37Weight (standard)kg1220
    38Electric motorDriving motorkw/60min11
    39Hydraulic driving motorkw/5min10
    40Control typeElectric drivingAC
    41Operating pressureHydraulic system pressurekg/cm²175
    3000kg Electric Counterbalance Truck , Battery Power Lift Truck For Factory3000kg Electric Counterbalance Truck , Battery Power Lift Truck For Factory3000kg Electric Counterbalance Truck , Battery Power Lift Truck For Factory
    After-sale service

    LTMG grants our clients a twelve-month-period or 2000 working hours warranty for any machine purchased from us.
    LTMG can also help clients coordinate with trained service personal to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity.
