    Short Wheelbase 1800kg LPG Forklift Truck For Warehouse CE | ISO Certification

    Ask Lasest Price
    Brand Name : LTMG
    Model Number : FG18
    Certification : CE/ISO
    Price : USD 9123-10365 PER SET
    Supply Ability : 500 Set/Sets per Month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    Short Wheelbase 1800kg LPG Forklift Truck For Warehouse CE | ISO Certification

    CE | ISO Certification 1.8 ton lpg forklift truck 1800kg short wheelbase forklift


    Features of 1.8 ton lpg forklift truck

    Hydraulic System:
    1. Hydraulic System rationally adopts supple and stiff tubes to reduce pressure loss,accelerating the lift of mast. Hydraulic units employ the seal units imported from Japan and passing thousand of tests.
    2. Heat Dissipation System:
    3. Newly adopted advanced radiator improves the radiator cooling performance greatly .Advanced heat dissipation technology improves heat dissipation channel,which enhances the truck heat dissipation capability further./Counterbalanced Diesel Forklift


    Electrical System:
    Electric system adopts advanced wiring harness,waterproof parts and widespread multirun use to improve the circuits security and stability.Without tool,the circuit integration can be maintained just by hand.


    The specifications of CE | ISO Certification 1.8 ton lpg forklift truck 1800kg short wheelbase forklift

    SpecificationManufacturer   LTMG
    Model  Power shift T/MFG18
    Operator type   Driver/seat
    Wheel Front/rear 2/2
     Free lift  mm155
    Tilt range Mast forward/backwarddeg6/12
    Overall length(without fork)  mm2245
    Total width  mm1070
    Mast height ( fork lowering)  mm1995
    Overall height fork raised ( with backrest)  mm4030
    Height to head guard  mm2060
    Front face of fork to front axle  mm395
    Min. right angle stacking aisle  mm2435
    PerformanceSpeedMax Travellingfull loadkm/h14
    no loadkm/h14.5
    Liftingfull loadmm/s440
    no loadmm/s500
    Loweringfull loadmm/s370
    no loadmm/s530
    Max.drawbar pull full/no loadKg1130/690
    Gradeability at 1.6km/h full/no load%21/18
     Weightfull loadfrontkg3580
    distributionrearkg470
     no loadfrontkg1110
     rearkg1440
    Chassis&Wheelsfront wheel   6.50-10-10PR
    rear wheel   5.00-8-10PR
    Wheelbase  mm1425
    Treadfront mm890
    rear mm900
    GroundAt lowest point(mast) mm115
    clearenceFrame mm105
    BrakeService brake  Hydraulic-foot pedal
    Parking brake  Mechanical-hand lever
    Drive LineBatteryVoltage/capacity  12/80
     Rated power kw/rpm34.3/2500
    Rated torque Nm/rpm138/1800
    Number of cylinders  4
    Placement L2.369
    Fuel tank capacity  L50
    TransmissionSpeed forward/backward  1-1 power shift T/M
    Operating pressureHydraulic system pressure Kg/cm²180

    1.8 ton lpg forklift truck

    Short Wheelbase 1800kg LPG Forklift Truck For Warehouse CE | ISO CertificationShort Wheelbase 1800kg LPG Forklift Truck For Warehouse CE | ISO CertificationShort Wheelbase 1800kg LPG Forklift Truck For Warehouse CE | ISO Certification


    After-sale service
    Nowadays we have been sell more than 100 countries. All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
    If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.

    Detail clauses and policies please see to our website and product's quality certificate.
