LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power

    Buy cheap LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power from wholesalers

    Buy cheap LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power from wholesalers
    • Buy cheap LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power from wholesalers
    • Buy cheap LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power from wholesalers
    • Buy cheap LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power from wholesalers

    LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power

    Ask Lasest Price
    Brand Name : LTMG
    Model Number : LT25J
    Certification : CE,ISO
    Price : USD 108160-13056 PER SET
    Supply Ability : 300 units one month
    Delivery Time : 35 days
    • Product Details
    • Company Profile

    LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power

    23 ton to 25 ton lumbering log transport wood grabbing machine loader for sale

    1, Good cost performance: Adopting full hydraulic transmission, it can bring the power of engine into full play amply. Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission. It enables the loader working efficiency and easy maintenance

    2, High productivity: Perfectly designed to enable the machine have super lifting force and automatic leveling at high position.

    3, Good capability in climbing the slope: 4-wheel driven, strong driving power.

    4, Operation flexible: Center-point frame articulated and small turning radius makes it convenient to work in confined places.

    5, Safe and reliable: Single-line air-assisted brake system.

    6, Going-through capability: The rear axle can swing around the center hanger frame, improved the going-through capability of the whole machine.

    7, Operation comfort: Continuously variable transmission, full hydraulic steering system steady and reliable .


    1. For the log grapple, the steel material of grapple in LT25J is Quenched integral Anti-wear made in Japan. Specially designed for the heavy log,effectively prevent any break, much stronger than the other Chinese manufacturer.
    2. The steel radial tires, which is much durable than the Nylon tires. The price is also more than twice of the Nylon tires of other manufacturer.
    3. Also the frame, cab and many other details are reinforced to adjust the tropical environment to make sure the high quality. L25J frame is also use the same design and dimensions with Japanese Komatsu 470 loader.

    The specification of 25 ton log loader with grapple

    Operating weight35,000kg
    Engine modelWD12G336E211
    Rated engine power247kw
    Rated rotate speed2200r/min
    Max. torque1350N.m
    Max. dumping height3600mm
    Rated load25T
    NO. of shiftsForward 4 For Reverse 2
    Driving speed
    Forward/Reverse Ⅰ0-6.5km/h
    Forward/Reverse Ⅱ0-12.3km/h
    Forward Ⅲ0-24km/h
    Forward IV0-41km/h
    Grade ability≥25°
    Max. traction force≥192KN
    Breakout force≥331kN
    Turning angle35°±1°
    Overall length10100mm
    Overall width3430mm
    Overall height3980mm
    Wheel base4200mm
    Track base2830mm
    Torque converterModel: YJ375X3 ratio
    torque ratio:3.166
    Cycling time16s
    Tire type29.5R29

    LTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated PowerLTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated PowerLTMG 25 Ton Lumbering Log Loader Grapple For Wood Grabbing 247kw Rated Power

    After-sale service


    Nowadays more than100 agents around the world can supply LTMG professional after-sale service.
    All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
    Detail clauses and policies please check our website and product certificate.
