    Walk Behind Electric Pallet Stacker Ergonomic Design Customized Lifting Height

    Ask Lasest Price
    Brand Name : LTMG
    Model Number : FEP 2T
    Certification : CE, ISO
    Price : USD 2000 PER SET
    Payment Terms : T/T, Western Union, MoneyGram,, L/C
    Supply Ability : 300 unit per month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    Walk Behind Electric Pallet Stacker Ergonomic Design Customized Lifting Height

    2 ton electric pallet stacker with 2m 3m 4m 5m lifting height


    2 ton electric pallet stacker feature


    1. Capacity from 1.0t-2.0t, lift height(1t-1.5t) 1.6m-5.0m, 2ton from 1.6m-3.0m
    2.it is very convenient to pick up goods, the capacity of storage compartment in front of the operator is 60kg
    3. Advanced power steering system (EPS) handle ensures effortless and highly efficient maneuver ability
    4. Ergonomic human engineering design provides the convenience and confort operation
    5. combinig of regenerative brake and electronmagnetic brake provide safe and reliable brake
    6. Safety features include a horn and belly reverse button.


    The Specification of 2 ton electric stacker


    Model FEP 2T
    Type Narrow legs
    Mast type 2-Stage STD
    Load capacitykg2000
    Load centermm600
    Wheel basemm1325
    Operating type Walkle/Stand on
    Wheels
    Wheel type PU
    Wheel quantity driving wheel/Balance wheel/Bearing wheel 1/2/4
    Demension
    Standard lift heightmm3000
    Lowered fork heightmm86
    Fork size(length/width/thickness)mm1150(1200)/180/60
    Overall lengthmm1970/2390
    Overall widthmm1050
    Outside with between legsmm570/600/650/685
    Inside with between legsmm180/230/280/315
    Min.turning radiusmm1630/1990
    Min.aisle width for pallets 800×1200mm2180/2580
    Min.aisle width for pallets 1000×1200mm2210/2600
    Min.groud clearancemm30
    Performance
    Travel speed,laden/unladenkm/h5/5.5
    Lift speed,laden/unladenmm/s80/120
    Travel speed,laden/unladenmm/s80/90
    Gradeability,laden/unladen%‘5/8
    Electric configuration
    Drive motor /Lift motor/Steering motorkwAC1.5/DC3.0/DC0.15
    Battery voltageV24
    Battery capacityAh280
    Brake Electromagnetic/Regenerative
    Controller Curtis
    Weight
    Battery weightkg235
    Service weight with batterykg1280

    Walk Behind Electric Pallet Stacker Ergonomic Design Customized Lifting HeightWalk Behind Electric Pallet Stacker Ergonomic Design Customized Lifting HeightWalk Behind Electric Pallet Stacker Ergonomic Design Customized Lifting Height


    After-sale service


    Nowadays more than 100 agents around the world can supply LTMG professional after-sale service.
    All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
    Detail clauses and policies please see to our website and product’s quality certificate.
