    LTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And Joystick

    Ask Lasest Price
    Brand Name : LTMG
    Model Number : LT955
    Certification : CE, ISO
    Price : USD 34800-45000/unit
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 300 unit per month
    Delivery Time : 30days
    • Product Details
    • Company Profile

    LTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And Joystick

    5t front end loader with 3m3 bucket , air conditioner, Joystick, 3-way valve

    LTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And JoystickLTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And JoystickLTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And Joystick

    5t front end loader feature


    1, Good cost performance: Adopting full hydraulic transmission, it can bring the power of engine into full play amply. Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission. It enables the loader working efficiency and easy maintenance

    2, High productivity: Perfectly designed to enable the machine have super lifting force and automatic leveling at high position.

    3, Good capability in climbing the slope: 4-wheel driven, strong driving power.

    4, Operation flexible: Center-point frame articulated and small turning radius makes it convenient to work in confined places.

    5, Safe and reliable: Single-line air-assisted brake system.

    6, Going-through capability: The rear axle can swing around the center hanger frame, improved the going-through capability of the whole machine.

    7, Operation comfort: Continuously variable transmission, full hydraulic steering system steady and reliable .


    The specification of 5t front end loader


    Operating weight16.1T
    Rated load5T
    Bucket capacity3m³
    Engine modelWD10G220E23
    Rated engine power162KW
    Rated rotate speed2000r/min
    Max.torque745.3N.m
    Breakout force145KN
    Driving speed
    Forward Ⅰ0-11.5km/h
    Forward Ⅱ0-38km/h
    Reverse Ⅰ0-16km/h
    Gradeability28°
    Overall length7460mm
    Overall width2870mm
    Overall height3220mm
    Buchet width3000mm
    Wheel base2870mm
    Track base2260mm
    Min.ground clearance450mm
    Max.dumping height3100mm
    Max.dumping reach1310mm
    Torque converterSingle stage,4elements
    NO.of shifts1 Forwards 2/Reverse 1
    TransmissionPlanet-type
    Raise time≤6.8s
    Total≤12.5s
    Tyre type23.5-25

    LTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And JoystickLTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And JoystickLTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And JoystickLTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And JoystickLTMG optional engine beilian tranmission 5 Ton Wheel Loader Front End Loader With AC And Joystick


    Nowadays more than 60 agents around the world can supply LTMG professional after-sale service.
    All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
    Detail clauses and policies please see to our website and product’s quality certificate.
