    LTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ce

    Ask Lasest Price
    Brand Name : LTMG
    Model Number : FDR50
    Certification : CE/ISO
    Price : USD 20968-24832/Unit
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 300 Set/Sets per Month
    Delivery Time : 35days
    • Product Details
    • Company Profile

    LTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ce

    LTMG 5ton rough terrain forklift 4WD all terrain forklift with ce

    LTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ce

    Product Information

    LTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ceLTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ceLTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ceLTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ce
    LTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ce

    Features of 5ton Rough terrain Forklift

    LTMG rough terrain forklift is suitable for bad road conditions, such as soft soil, grassland, wading, jungle, desert, mountain, mine and other rough road conditions, loading and unloading of materials, palletizing, short-distance transportation and other operations.
    1. The whole hydraulic electronically controlled gearbox, steering and pilot workmanship make the whole machine more flexible.
    2. Equipped with double-bridge four or six-wheel drive, which has large traction and makes it more safe and stable.
    3. The articulated frame has a small turning radius and the walking operation handle adopts the advanced technology of German ZF.
    4. Install tire clamp attachments which to replace large-scale mining machinery tires, and configure various special-shaped attachments.


    The Specification of 5ton diesel rough terrain forklift

    Technical Parameter
    1.1ModelFDR50
    1.2Power TypeDiesel
    1.3Drive Type2WD/4WD
    1.4Rated Capacitykg5000
    1.5Load Centermm500
    Dimension Parameter
    2.1Lift Heightmm3000-8000
    2.2Fork Size(L*W*H)mm1220×150×55
    2.3Mast inclination angle (F/R)Deg612
    2.4Overall Length without fork3500
    2.5Overall Widthmm1760
    2.6Overall Heightmm2500
    2.7Mast Heightmm2500
    2.8Head Guard Heightmm2470
    2.9Min. Ground Clearancemm320
    2.1Min.Turning Radiusmm3200/3880
    2.11Wheelbasemm1850/1860
    2.12Front wheel treadmm1430
    2.13Rear wheel treadmm1310/1380
    2.14Operating Weightkg7000
    Performance Parameter
    3.1Max.Travel Speed of unladenKmh36
    3.2Lifting Speedmms520
    3..3Lowering Speedmms490
    3.4Max. Gradeability of laden≧40
    Tire
    4.1Front Tyre16/70-20
    4.2Rear Tyre10-16.5
    Engine and Gearbox
    5.1BatteryVAh1280 / 2460
    5.2Standard EngineYunNei
    5.3Engine ModelYN4EZ085-32CR
    5.4Rated Power/RPMkw67
    5.5Fuel Tank CapacityL90
    5.6Gearbox Model280
    5.7Transmission TypeHydrodynamic

    LTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ceLTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ceLTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ceLTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ceLTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ce

    LTMG 5ton rough terrain forklift 2WD 4WD all terrain forklift with ce


    FAQ

    1.What Certificate do you have?
    LTMG workshop meet with the ISO9001:2008 Quality System.
    All of our products with CE certificate. Some of our products meets the EPA requirements.

    2. Can you customize and design as the clients' requirement?
    LTMG will try its best to meet all kinds of clients' special requirements.
    However, All the customizing and refit should be implemented safely and scientifically.
    The colors can be painted as client's need.

    3.How long is the warranty of your products?
    Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

    4. Can you produce the products labeled with the client's brand?
    With the authorization of the brand, we can OEM for our clients.

    5. What payment terms do you accept?
    Normally 30% T/T in advance as deposit, blance paid before shipment.
    100% L/C at sight issued by world famous bank with good faith is also available.

    6.Delivery time:
    Standard configuration products are always in stock.
    The production period of Customizing products is 30 days.
